RF/Microwave Laminates

High Reliability substrates for extreme conditions

A complete spectrum of reliable, high-value substrates for commercial and avionics & aerospace critical microwave components, antennas and subassemblies. AGC high frequency very low loss RF PCB material is tailored to meet the needs of the RF and Microwave markets. The very advanced electrical performance and very high reliability of this PCB material is designed for multiple high temperature lead-free assemblies and high layer count printed circuit board designs requiring very high levels of reliability. AGC RF/Microwave laminates offer flexibility and freedom to design high performance RF and Microwave printed circuit boards. Avionics phase array radar antennas and automotive radar sensor antennas are excellent examples of success stories over the years.

产品名称 说明 DK DF TG (° C) TC (W/mK) IPC 斜格表
EZ-IO-F 基于纳米技术、扩散布纹和聚四氟乙烯的热稳定复合材料 2.80 +/- 0.05 0.0015 N/A 0.53 4103A/230
NF-30 陶瓷填充型聚四氟乙烯复合材料,不含布纹玻璃纤维增强材料 3.0 +/- 0.04 0.0013 N/A 0.5 4103A/230
RF-10 低损耗、高 DK 材料 10.2 +/- 0.3 0.0025 N/A 0.85 4103A/280
RF-30A N/A N/A N/A N/A N/A N/A
RF-35HTC N/A N/A N/A N/A N/A N/A
RF-35TC 导热低损耗层压板 3.5 +/- 0.05 0.002 N/A 0.92 4103A/240
RF-35TC-A 导热低损耗层压板 3.5 +/- 0.05 0.002 N/A 0.83 4103A/240
RF-60TC 高 DK、高导热系数材料 6.15 +/- 0.15 0.002 N/A 1.05 4103A/270
TLC-32 低成本射频层压板 3.2 +/- 0.05 0.003 N/A 0.24 4103A/240
TLE-95 耦合器专用薄型介电基材 2.95 +/- 0.05 0.0026 N/A 0.2 4103A/230
TLF-35A 低成本PA 基材 3.5 +/- 0.05 0.0026 N/A 0.37 4103A/240
TLX-8 高容量天线材料 2.55 +/- 0.04 0.0018 N/A 0.19 4103A/200
TLY-5 极低 DK 基材 2.2 +/- 0.02 0.0009 N/A 0.22 4103A/200
TLY-5A 极低 DK 基材 2.17 +/ 0.02 0.0009 N/A 0.22 4103A/200
TLY-5Z 低 DK、低 Z 轴层压板 2.2 +/- 0.04 0.0015 N/A 0.2 4103A/200
TSM-DS3 尺寸稳定的低损耗层压板 3.0 +/- 0.05 0.0014 N/A 0.65 4103A/230
TSM-DS3b 尺寸稳定的低损耗层压板 3.0 +/- 0.04 0.0014 N/A 0.65 4103A/230
TSM-DS3M 尺寸稳定的低损耗层压板 2.94 +/- 0.05 0.0014 N/A 0.65 4103A/230
